MATERIAL:

1. PEDESTAL: UL94V-O PBI engineering compound, Gallant

2. Upper cover: UL94V-OPBT engineering plastic, red, blue

3, push button; UL94V-0 PA66, White

4. Wall: Inscription Bronze Best Gold.

Mechanical Properties:

1. Operating Force: 8 & Lt;

2. Push button stroke 200om

3. Operating temperature: -20C ~ + 70C

4. Storage temperature: -40C ~ + 85

electrical characteristics:

 1. Electrical Life: Each switch is tested at a voltage of 24VDC and current of 25A. It can be dialed back and forth 2000 times.

2. Switching infrequent rated: 100mA, withstand voltage 50VDC.

3. Switching frequent rated current: 25mA, withstand voltage 24VDC.

4. Contact impedance a Max. 50m0 initially, B Max. 100m0.

5 after testing. 1000.500VDC.

6. Voltage Strength: 500VAC/1 Min.

7. Extreme capacitance: MAXIMUM 5PF

8. Circuit: SINGLE-CONTACT SINGLE-CHOICE

 WELDING AND CLEANING PROCESS:

1. During all operations, please ensure that the switch is at the“Off” position.

2.Wave Welding: The recommended lock temperature is 250 + 5C, 3 ~ 5 seconds.

3. Hand Welding: Use 30w iron to control the temperature at 320C, the welding time is about 2 seconds.

4, cleaning process cleaning using ultrasonic mode, can give better results, the use of steam mode, the temperature can not exceed 51c.
